Different types of inverter power installation methods
Different types of inverter power installation methods

Different types of inverter power installation methods

As the electrical conversion equipment of the photovoltaic power station, the inverter plays an important role in the whole power station. A photovoltaic inverter is an electronic device that converts electrical energy generated by low-voltage DC into AC electrical energy. Connecting to loads or connecting to the grid is the core equipment in the photovoltaic system.

Where is the inverter installed?

Universal Ground Distributed Project Installation Solution
It can be installed under a nearby string of components, using a fixed bracket mount or a pillow mount to secure the device directly to the column. This solution needs to pay attention to the support height of the bracket and the column and the photovoltaic inverter to prevent it from being placed too low in rainy days.

Installation scheme for large industrial and commercial plants
Large-scale industrial and commercial roofs are generally empty roofs, without roof sheds and parapets, where photovoltaic inverters can be hung. In order to reduce the cost of cables, they generally need to install brackets and hang the inverter on their own brackets. The load and fixed form of the inverter and the anti-typhoon ability of the coastal area need to be considered.

Common household distributed project roof power station installation solutions
The photovoltaic inverter should be installed on the south wall as much as possible. The installation of the machine must have a suitable height from the ground in order to observe and read the LED display. When installed outdoors, the inverter should be protected from rain and sun, and avoid direct sunlight and rainwater immersion.

Systems with Microinverters
Microinverters can be mounted directly on a rack beneath the module or integrated with the module using a module-oriented design. The micro-inverter is small in size, basically does not occupy the installation space independently, and the distributed installation is easy to configure. It can make full use of the space and adapt to the application of different installation directions and angles.
The above are the installation methods of different types of inverter power supplies and the relevant content of where to install them. Thank you for reading, you can follow BWITT official website.
