220V/50Hz sinusoidal AC power inverter 48Vdc & 220Vdc parallel inverter modular telecom inverter

parallel kit for solar inverter auto electric power inverter

See more pictures

Description:

BWT-DT1500 serial 48Vdc &220Vdc modular parallel connection inverter is an inversion device that converts 48V dc/220Vdc power supplied by communication DC power supply into 220V/50Hz sinusoidal AC power.

Model：

48Vdc & 220Vdc-1-3kva

- +

ADD TO INQUIRY 0

- +

ADD TO INQUIRY 0

- +

ADD TO INQUIRY 0

Send Email To Us Contact Now

Product Detail

Parameters

Inquiry Now

220V/50Hz sinusoidal AC power inverter 48Vdc & 220Vdc parallel inverter modular telecom inverter

It is designed with complete isolation of input and output, and allows hot plugging and parallel connection redundancy. With small size and convenient parallel connection, it is a product specially designed for users with high requirements for power supply reliability and maintainability.

Tags：

High inverter efficiency 240v dc to 240 ac power inverter 15kw parallel inverter

Rectifier 220V AC 48V DC 1.8KW 100 amp dc power supply Modular Telecom Rectifier System

Send your message to us:

Product recommendation

Product model	24 Serial	48 Serial	110 Serial	220 Serial
1000VA	NO	BWT48/220-1KVAS	NO	NO
2000VA	NO	BWT48/220-2KVAS	NO	BWT220/220-2KVAS
3000VA	NO	BWT48/220-3KVAS	NO	BWT220/220-3KVAS
Other	OEM	OEM	OEM	OEM

Product form	Rated power	24KVA	1-3KVA
	Size (W×H×D）(mm)	19"/3U+	9.5"/1U / 9.5"/2U
		21688421*+	21644426 / 21688421
Input parameter	DC Input Voltage	48VDC/220VDC
	DC Input Range	42～59VDC/190～270VDC
	Bypass Input Range	176～264(Can be adjustable according customer)
	Bypass Switch time	5～12ms
Ac output	Rate output Voltage	220VAC
	Rate output Frequency	50Hz
	Load regulation	<1%
	Frequency accuracy	<0.1%
	peak factor	3：1
	Waveform distortion	Resistance full load＜3%，nonlinear full load＜5%
	Dynamic response	Voltage transient range＜3%，transient response recovery time≤60ms（load from 0 to 100）
	Parallel uneven flow	＜3% rated current RMS
	Overload capacity	Load current ＜105%, continuous work Load current 105～125%, continuous work 10min shutdown Load current 125～150%，continuous work after 1min shutdown Load current＞150%，after 20ms shutdown
	Protection function	Input connection protection, input under voltage and over-voltage protection, output overload protection, output short circuit protection, over temperature protection
Communication	Communication interface	RS485
Work environment	Insulation strength	2KVac，1min
	Noise (1 m)	＜45dB
	Operating ambient temperature	－10～50℃
	Transport and storage temperature	－40～70℃
	Relative humidity	0～90%, no condensation
	Relative altitude (M)	≤3000m，1500～3000m, 1% decrease in output for every 100 m increase
